215585 131 Revision A
7.2 Lubrication Points
Unless otherwise specified, use high-temperature, extreme-pressure (EP2) performance grease with 1% max molybdenum
disulphide (NLGI grade 2) lithium base.
$
%
&
'
(
)
Figure 7.5: Lubrication Points
A - Bearing, Finger Conditioner B - Hitch Pivot C - Hitch Swivel
D - Idler Pivot E - Bearing, Roller Conditioner F - Bearing, Roller Conditioner
LUBRICATING THE ROTARY DISC PULL-TYPE
