MacDon R113 - Priming the Hitch Swing Cylinder

215585 111 Revision A
6.2 Priming the Hitch Swing Cylinder
The hitch swing cylinder must be primed before it is connected to the rear arm link.

$
%
Figure 6.5: Remote Control
1. Move the transport switch on the remote control to lower
position (B) and ensure that light (A) is illuminated. The
hitch swing circuit will now be active.
COMPLETING ROTARY DISC PULL-TYPE ASSEMBLY
