215585 152 Revision A
9. Clear all bystanders from the area.
10. Start the engine, and raise the rotary disc pull-type fully.
11. Shut down the engine, and remove the key from the ignition.
12. Close the lift cylinder lock-out valves on both sides of the rotary disc pull-type. Valve handles should be in the closed
position (90° angle to the hose).
13. Remove the inspection plug, and add some oil. Loosely install the inspection plug.
14. Open the lift cylinder lock-out valves on both sides of the rotary disc pull-type. Valve handles should be in the open
position (parallel to the hose).
15. Lower the rotary disc pull-type onto the blocks, then repeat Step 5, page 151.
16. Recheck the oil level.
$
%
Figure 8.26: Cutterbar Oil Inspection Plug
17. Check O-ring (B) for breaks or cracks, and replace if
necessary.
18. Install plug (A) and O-ring (B). Tighten securely.
19. Close the cutterbar doors.
PERFORMING PREDELIVERY CHECKS
