Maeda MC815C - Page 201

4-7
Equipment
name
Port
Joint Hose/Piping Joint
Port
Connection
destination
No.
Name
No.
Name
No.
Name
Part No. Part No. Part No.
Hydraulic oil
tank
(106-1186700)
- (12)
Hose nipple
4
Suction hose 2
5
Pump suction 2
S1
Hydraulic
pump
(106-2179000)
103S98300000
[HN-1040  40×R1 ・ 1/2]
106-4690100
[
51×38.1×1100L]
S106J3644000
Hydraulic
pump
(106-2179000)
A1 (6)
Male 90° elbow with
plate
1
Hose EP1SM
(3)
Male 90° elbow
with plate
G
Shuttle
manifold
block
22611-11160
[1071-08 HYDEX]
106-4685000-02
[PA2808C-C×850L]
22611-11160
[1071-08 HYDEX]
A2 (6)
Male 90° elbow with
plate
2
Hose EP2SM
(3)
Male 90° elbow
with plate
A
22611-11160
[1071-08 HYDEX]
106-4685100-02
[PA2808C-C×850L]
22611-11160
[1071-08 HYDEX]
A3 (7)
Male 90° elbow with
plate
3
Hose EP3SM
(4)
Male 90° elbow
with plate
D
22611-11130
[1071-04 HYDEX]
106-4685200
[PA2808C-C×970L]
22611-11130
[1071-04 HYDEX]
Figures in No. parentheses ( ) refer to equipment names, and connection point parentheses ( ) to part
numbers
