BA053101-en
LEVEL 4
• Use this button to display the vehicle data.
• Use this button to display the RPM setting.
• Use this switch button to smooth the power curve (P-drag) by extrapola-
tion and then to store.
1 Use the button <F7 CURVE SELECTION>.
The following screen appears:
2 Use the keys 1 to 4 or the appropriate but-
tons to blend in the individual performance
curves.
3 Using the keys 5 to 7 or the appropriate
buttons a max. of 3 additional measurements
(torque and engine power), if loaded, can be
blended in and out in the background.
4 A max. of 3 additional curves can, if loaded,
be blended in or out in the background with
the selection boxes or the appropriate but-
tons.
5 With <F7 MAX. VALUES> the max. values
are re-displayed.
