Mahr GmbH • Millimar C1202
1.5 Operating elements and interfaces
1.5.1 Display and operating keys
Display
Operating keys
Scale
Master measurement
active
Warning limit
Measured value
Tolerance limit
Unit
Measuring
channel active
Scale end value
Angle in
degrees
Feature 1
Feature 2
Feature 3
Key function
Hand for selecting a feature
