Mahr Millimar C 1202 - Setup 3; Factor C1; Factor C2

60
Mahr GmbH • Millimar C1202
5.3 Setup 3
– Press the ON/OFF key
=> Menu appears.
– Press Ó,
▼
or
▼
and to select
Setup 3.
5.3.1 Factor C1
Set the channel factor. Measured
values from the sensor to channel 1
are multiplied by this factor.
– Select the Factor C1 submenu using
the ▼ or ▲ key.
– Select using 4 key or exit submenu
using the Ó key.
– Use the
▼
key to select the digit and
the ▼ or ▲ key to enter the relevant
value.
– Use the 4 key to conrm the value or
Ó to exit the submenu.
5.3.2 Factor C2
Set the channel factor. Measured
values from the sensor to channel 2
are multiplied by this factor.
Implement the settings as described
under 5.3.1 Factor C1.
