Mahr GmbH • Millimar C1202
8 Technical data
8.1 Compact length measuring instrument Millimar C 1202
Product type C 1202
Order no. 5312025
Compatibility: Depends on N 1700 module being used
Display: TFT color display, 4.3 inch, 480 (W) x 272(H) pixels
Keypad: Membrane keypad, 1 million actuations
Units: μm, mm, inch, degrees°, Rad, degrees° Min´ Sec´´
Range of digital display: ±999.99999 mm; ±999999.99 µm;
±39.3700000 inch
±999.99999°; ±6.9800000 rad; ±399° 59´ 59´´
Range of analog display:
Measuring range
/ µm
±5000 ±2000 ±1000 ±300 ±100 ±30 ±10 ±3
Measuring range
/ mm
±5 ±2 ±1 ±0.3 ±0.1 ±0.03 ±0.01 ±0.003
Measuring range
/ inch
±0.19 ±0.07 ±0.03 ±0.01 ±0.003 ±0.001 ±0.0004 ±0.0001
Dial graduation /
µm
500 200 100 20 10 2 1 0.2
Measuring range /
degrees
±100° ±30° ±10° ±3° ±1° ±0.3° ±0.1° ±0.03°
Measuring range
/ Rad
±1.5 ±0.5 ±0.1 ±0.05 ±0.01 ±0.005 ±0.001 ±0.0003
Measuring range /
Degrees Min Sec ±100° ±30° ±10° ±3° ±60´ ±18´ ±6´ ±1´
Scale division /
degrees
10° 2° 1° 0.2° 0.1° 0.02° 0.01° 0.002°
Resolution:
μm: 10; 1; 0.1; 0.01* (*only with N 1702 M-HR)
mm: 0.01; 0.001; 0.0001; 0.00001*
inch: 0.0001; 0.00001; 0.000005; 0.0000005*
Degrees°: 0.001°; 0.0001°; 0.00005°
Rad: 0.00001; 0.000001; 0.0000005
Degrees° Min´ Sec´´ 1´´
