Mahr GmbH • Millimar C1202
Tolerance display: Background color green / yellow / red
Measuring ranges, inductive probe: Depends on N 1700 module being used
Sensor inputs: via N 1700 module, maximum 2
Data transfer rate USB: 1 feature active: 28 values per second
Measuring combinations: +A / -A / +B / -B / +A+B / +A-B / -A+B / -A-B
Measuring functions: None, Max, Min, Max-Min, (Max+Min)/2,
Average, atan
Features: 3
Refresh rate: 20 to 40 fps (frames per second)
depending on measuring task
Error limit, digital display
with measuring module N 1702 M: 0.2 μm / 0.3% of displayed probe value**
with measuring module N 1702 M-HR: 0.04 μm / 0.3% of displayed probe value**
** The larger value applies
Error limit, scale display: 0.25 % of scale end value /
0.3% of displayed value ***
*** The larger value applies
Data interface: USB,
hardware interface: USB, control input, RS485, Micro SD slot
Power supply: Mains powered 100 -240 Volt / 12V, 1.5 A
IP protection class: 42
Weight excluding module: 778 G
Operating temperature range: 0°C – 40°C ****
Storage temperature range: -10°C – 50°C
Dimensions W/H/D: Angle of the display 25 degrees:
130/115/140 mm
Angle of the display - 90 degrees:
130/175/140 mm
Distance between mounting holes: 62 mm
**** To achieve maximum accuracy, the instrument must be at operating temperature.
Operating temperature is reached after approx. 30 mins. of being switch on.
Theinformation on accuracy is based on a room temperature of 20°C in accordance
with ISO 1.
