Manitowoc Grove GMK 4100L-1 User Manual

Tilting play measurement report
• Always measure the current tilting play as described in Section Measuring tilting play, p. 8 - 28.
Base value:
............... mm
Max. permissible wear: + 3.2 mm Max. permissible tilting play: ............... mm
Date Current tilting play Ball slewing bearing Signature
–135° (A) –45° (B) +45° (C) +135° (D) OK defective replaced on
