Manitowoc Grove GMK 4100L-1 - Draining off Water from Fuel Filter 1

Maintenance work on the carrier
7.4 Fuel system
7 - 28 3 302 364 en Maintenance manual
GMK 4100L-1
25.11.2016
7.4.1 Draining off water from fuel filter 1
Spare parts
and tools
– Receptacle, approx. 5 ltr (1.5 gal); à p. 2 - 4.
Prerequisites – The truck crane must be level and on outriggers;
à Operating Instructions.
– The main boom must be fully raised;
à Operating Instructions.
– The engine must be switched off and secured against unauthorised
use
;
à p. 2 - 3.
Draining off water
• Place a receptacle underneath the filter.
• Open the valve (1).
• If the consumable that emerges is clean,
close the valve by hand.
• Remove the receptacle and properly
dispose of the drained consumable.
D
O
Risk of environmental damage due to leaking consumables.
Always let consumables drain into suitable receptacles. Wipe up
any c
onsumables that escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
