Lubricants and consumables
6.1 Lubricants
25.11.2016
Maintenance manual 3 302 364 en 6 - 3
GMK 4100L-1
6.1.2 Lubricant applications list
Consec.
no.
Lubricant
type
Usage Fill
quantity
in litres
(gal)
Mainte-
nance
interval
1
Engine oil Diesel engine; à p. 7 - 25 34 (9.0) Y 2
2
Gear oil Transmission; à p. 7 - 42 15.5 (4.1) Y 5
3
Gear oil
Transfer case;
à p. 7 - 46 14 (3.7) M 6
1. Axle line axle centre drive; à p. 7 - 57 13.0 (3.5) M 12
4. Axle line axle centre drive; à p. 7 - 57 13.0 (3.5) M 12
2. Axle line axle centre drive; à p. 7 - 57 15.0 (4.0) M 12
3. Axle line axle centre drive; à p. 7 - 57 16.5 (4.4) M 12
6 or 8 x final drives; à p. 7 - 62 2.7 (0.7) M 12
4
Gear oil
Angle drive type A;
à p. 7 - 52 7.2 (1.9) M 6
Angle drive type B; à p. 7 - 52 8.6 (2.3) M 6
5
Gear oil 8 x suspension struts; à p. 7 - 83
1.5 (0.4)
each
M 1
6
Gear oil
2 x hoists;
à p. 8 - 11
3.3 (0.9)
each
M 12
2 x slewing gears; à p. 8 - 19
0.9 (0.24)
each
M 12
7
Hydraulic oil
Carrier hydraulic tank;
à p. 7 - 107 165 (44) M 12
Superstructure hydraulic tank; à p. 8 - 42 650 (172) M 12
8
Hydraulic oil Driver's cab tilting system; à p. 7 - 2 1 (0,26) M 12
