Maintenance work on the superstructure
8.11 Hook blocks
25.11.2016
Maintenance manual 3 302 364 en 8 - 71
GMK 4100L-1
8.11 Hook blocks
8.11.1 Checking the sheaves
• Check the sheaves in the hook blocks for damage, wear, mobility
and extreme soiling.
Have damaged, worn, stiff or extremely soiled sheaves replaced by
Manitowoc Crane Care or an authorised GROVE dealer or your repair crew.
8.11.2 Lubricating
• Comply also with the à Run-in regulations, p. 4 - 1.
Grease, spare
parts, tools
– Grease gun from the tool set.
Prerequisites – The hook block has been reeved at least twice;
à Operating Instructions.
Lubricating
On the hook blocks supplied, the sheaves, crossheads and load hooks of the
axial bearings are greased.
H
The sheaves on the hook block often have no grease nipple and are
maintenance-free.
• Check all hook blocks for grease nipples. Hook blocks with grease nipples
must be serviced, hook blocks without grease nipples are maintenance-
free.
s
M 3
M 12
Lubricating
grease
Designation
to DIN 51502
Specification
classification
GROVE part no.
Grease KP - 1K - 50 DIN 51825 03233369
