Maintenance work on the carrier
7.8 Angle gear
7 - 50 3 302 364 en Maintenance manual
GMK 4100L-1
25.11.2016
7.8.1 General inspection
• Investigate any unusual noises in the angle gear.
• Check the transmission and the oil circuit (oil cooler, filter, hoses,
connections) for leaks. If consumables are leaking;
à Checking the oil level, p. 7 - 50.
• Check that pipes and hoses are tightly connected and undamaged.
If any damage is found, report it to
Manitowoc Crane Care or an authorised
GROVE dealer or an authorised specialist workshop.
7.8.2 Checking the oil level
Spare parts
and tools
Prerequisites – The truck crane must be raised on outriggers or parked over an
inspection
pit.
– The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
– The angle gear must be adequately cooled.
– The inspection opening and the interior space must be clean and free of
oil so that the fitter can work safely in the restricted space where the
angle gear is installed.
W
M 1
Designation Quantity GROVE part no.
Gasket 30 x 36 Cu DIN 7603 1 00117151
