Manitowoc Grove GMK 4100L-1 - Changing the Oil and Oil Filter

Maintenance work on the carrier
7.3 Engine
25.11.2016
Maintenance manual 3 302 364 en 7 - 25
GMK 4100L-1
7.3.8 Changing the oil and oil filter
Oil, spare parts,
tools
– Receptacle, approx. 40 ltr (11 gal);
à p. 2 - 4.
– Torque wrench for a torque of 55 Nm (40.5 lbf ft).
Prerequisites
• Find out the prescribed oil specification and about the need to shorten
the maintenance interval under special operating conditions;
à Engine manufacturer’s documentation.
• Find out about the safety instructions and the sequence of steps to change
the oil and the oil filter;
à Engine manufacturer’s documentation.
– The truck crane must be level.
– The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
Changing
s
Y 2
Engine oil
in litres (gal)
Designation
to DIN 51502
Specification
classification
GROVE part no.
34 (9.0) HD - CD MIL-L 2104 C
DB 228.5
SAE 5 W-30
03329588
Designation Quantity GROVE part no.
Oil filter with cover gasket 1 04163013
Original oil drain plug 1
04161529
O
Risk of environmental damage due to leaking consumables.
Always let consumables drain into suitable recep
tacles. Wipe up any
consumables that escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
