Manitowoc Grove GMK 4100L-1 User Manual

Maintenance work on the carrier
7.9 Axle lines
7 - 62 3 302 364 en Maintenance manual
GMK 4100L-1
25.11.2016
7.9.5 Final drives – Changing the oil
Oil, spare parts,
tools
1)
Additional equipment (2nd driven axle line)
– Drain channel.
– Receptacle, approx. 5 ltr (1.5 gal);
à p. 2 - 4.
Prerequisites – The truck crane must be raised on outriggers.
– The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
– The parking brake must be released.
M 12
Gear oil
in litres (gal)
Designation
to DIN 51502
Specification
classification
GROVE part no.
for each final
drive:
2.7 (0.7)
C - LPF MIL-L 2105 B
API-GL-5
Viscosity:
Hyp SAE 90
ISO - VG 220
00552891
for drive Designation Quantity GROVE part no.
8 x 6 x 8 Gasket 24 x 29 Cu DIN 7603 6 00117145
8 x 8 x 8
1)
Gasket 24 x 29 Cu DIN 7603 8 00117145
O
Risk of environmental damage due to leaking consumables.
Always let consumables drain into suitable receptacles. Wipe up any
consumables tha
t escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
