Manitowoc Grove GMK 4100L-1 User Manual

Maintenance work on the superstructure
8.3 Hoists
25.11.2016
Maintenance manual 3 302 364 en 8 - 11
GMK 4100L-1
8.3.4 Changing the oil/checking the oil
• Comply also with the à Run-in regulations, p. 4 - 1.
Oil, spare parts,
tool
s
– Receptacle, approx. 8 ltr (2 gal);
à p. 2 - 4.
Prerequisites – The truck crane must be level and in on-road mode; à Operating
Instructions
.
– The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
Changing the oil
at the hoist
H
During filling, the oil spreads only slowly in the hoist. The oil level therefore
rises quickly in the standpipe at first, then drops slightly and then eventually
rises again to its true level.
s
M 12
Gear oil
in litres (gal)
Designation
to DIN 51502
Specification
classification
GROVE part no.
3.3 (0.9)
for each hoist
C - LPF MIL-L 2105 B
API-
GL-4/5
Viscosity:
SAE 75 W-90 EP
ISO - VG 220
02313611
Synthetic oil; do
not mix this with
mineral-based
oils.
Designation Quantity GROVE part no.
Oil
inspection glass; complete 2
84012690
S
Risk of damage to the hoist gears.
The waste oil must be checked for abrasion particles. This test is used to
detect any damage at an early stage;
à p. 8 - 12.
O
Risk of environmental damage due to leaking consumables.
Always let consumables drain into suitable recep
tacles. Wipe up any
consumables that escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
