Manitowoc Grove GMK 4100L-1 User Manual

Maintenance work on the carrier
7.8 Angle gear
7 - 52 3 302 364 en Maintenance manual
GMK 4100L-1
25.11.2016
7.8.3 Changing the oil and the oil filter
Oil, spare parts,
tools
– Connecting piece and hose (tool box);
à p. 7 - 108.
– Receptacle, approx. 10 ltr (2.5 gal);
à p. 2 - 4.
Prerequisites – The truck crane must be raised on outriggers or parked over an
inspection
pit.
– The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
– The angle gear must be adequately cooled.
– The inspection opening and the interior space must be clean and free of
o
il
so that the fitter can work safely in the restricted space where the angle
gear is installed.
M 6
Gear oil
in litres (gal)
Designation
to DIN 51502
Specification
classification
GROVE part no.
7.2 (1.9)
for type A
8.6 (2.3)
for type B
MIL-L 2105 B
API-GL-5
Viscosity:
Hyp SHC 75-90
013733
44
Designation Quantity GROVE part no.
Angle gear:
Gasket 30 x 36 Cu DIN 7603
1 00117151
Filter:
Filter
1 03135866
Packing set 1 04161645
Oil cooler:
Drain plug with gasket
1 03326356
