Maintenance work on the carrier
7.6 Transmission
7 - 42 3 302 364 en Maintenance manual
GMK 4100L-1
25.11.2016
7.6.3 Changing the oil
Oil, spare parts
and tools
– Receptacle, approx. 20 ltr (5 gal);
à p. 2 - 4.
– Torque wrench for torque of 25 Nm (18.4 ft lbf) and 60 Nm (44.25 ft lbf).
Prerequisites – The gear oil must be at operating temperature (70 to 95 °C (160 to 200 °F)).
– The truck crane must be raised on outriggers or parked over an inspection
pi
t.
– The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
– The inspection opening are now accessible;
à p. 7 - 40.
Draining oil
Y 5
Gear oil
in litres (gal)
Specification
Classification
GROVE part no.
15.5 (4.1)
with oil cooler
Fuchs Titan
Cytrac MB Synth
API-GL-4; SAE 75 W-90
04162042
Designation Quantity GROVE part no.
Filter 1 03328342
Spring 1 03328343
Gasket 42 x 49 Al DIN 7603 1 03328344
Gasket 24 x 29 Cu DIN 7603 2 00117145
G
Risk of scalding from gear oil at operating temperature.
You could scald yourself by gear oil escaping in an uncontrolled manner at
operating temperature. Wear appropriate protective gloves and take care
not to come into contact with the gear oil.
O
Risk of environmental damage due to leaking consumables.
Always let consumables drain into suitable receptacles. Wipe up any
consumables tha
t escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
