Manitowoc Grove GMK 4100L-1 User Manual

Maintenance work on the carrier
7.15 Hydraulic system
25.11.2016
Maintenance manual 3 302 364 en 7 - 111
GMK 4100L-1
7.15.8 Changing the hydraulic oil filter
When changing the oil, all the oil filters must be replaced.
If a warning message appears, the symbol (1) in the
Warning submenu
indicates that you must change oil filters 1 and 2.
If a warning message appears, the symbol (1) in the
Warning submenu
indicates that you must change oil filter 3.
If a warning message appears, the symbol (1) in the
Warning submenu
indicates that you must change oil filter 4.
Filters 3 and 4 must be
replaced together after the first 50 hours in driving
mode and must then be replaced together annually (M 12) after this.
Spare parts
and t
ools
– Receptacle, approx. 5 ltr (1.5 gal);
à p. 2 - 4.
Prerequisites – The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
s
Designation Quantity GROVE part no.
Filter (for filters 1 and 2)
Packing set
2 03329152
2 04163599
Filter (for filters 3 and 4)
Packing set
2 03140253
2
03135867
