Maintenance work on the superstructure
8.5 Slewing bearing
8 - 30 3 302 364 en Maintenance manual
GMK 4100L-1
25.11.2016
8.5.5 Lubricating the locking of turntable
Grease, spare
parts, tools
–Brush.
Prerequisites – The truck crane must be level and in on-road mode;
à Operating
Instructions
.
– The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
Lubricating
• Familiarise yourself with the correct operation of the turntable lock;
à Operating Instructions.
• Grease the lubricating points (1) and (2) with
the brush.
M 12
Lubricating
grease
Designation
to DIN 51502
Specification
classification
GROVE part no.
Grease KP - 1K - 50 DIN 51825 03233369
