Maintenance work on the carrier
7.10 Wheels
25.11.2016
Maintenance manual 3 302 364 en 7 - 67
GMK 4100L-1
7.10 Wheels
7.10.1 Checking the tyres for damage
Prerequisites – The truck crane must be raised on outriggers.
– The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
– The parking brake must be released.
Checking
• Check all tyres for:
– Broken off tread blocks
–Dents
– Areas of uneven wear
– Whether the wear mark (1) has been
reached
• Replace any damaged tyres.
• If the tyres show varying degrees of wear,
change the wheels;
à Changing the wheels,
p. 7 - 70.
D
S
Risk of accidents due to uneven braking.
When replacing the tyres, only use the same quality of t
yres as those
originally fitted (dimensions, load bearing capacity, air pressure) so that the
driving characteristics are maintained.
Always replace all the tyres on an axle line.
