Maintenance work on the carrier

7.3 Engine

7 - 16 3 302 364 en Maintenance manual

GMK 4100L-1

25.11.2016

7.3.3 Checking the air filter

• Start the engine and monitor the display.

• If the symbol (1) is displayed, you must change the air filter.

• Switch the engine off.

Spare parts

and t

ools

Prerequisites – The engine must be switched off and secured against unauthorised use;

à p. 2 - 3.

Replacing the

air filter

• Undo all the clamps (1) and remove the

cover (2).

• Change the main filter (3) and the back-up

filter (4).

• Replace the cover and secure it with all the

clamps.

Designation Quantity GROVE part no.

Main filter 1 04158601

Back-up filter 1 04158602
