Maintenance work on the carrier
7.7 Transfer case
25.11.2016
Maintenance manual 3 302 364 en 7 - 45
GMK 4100L-1
7.7 Transfer case
• Comply also with the à Run-in regulations, p. 4 - 1.
7.7.1 General inspection
• Investigate any unusual noises made by the transfer case.
• Check the transfer case and the connections for leaks. If consumables
are leaking;
à Checking the oil level, p. 7 - 45.
• Check that pipes and hoses are tightly connected and undamaged.
If any damage is found, report it to
Manitowoc Crane Care or an authorised
GROVE dealer or an authorised specialist workshop.
7.7.2 Checking the oil level
Spare parts
and tools
Prerequisites – The truck crane must be raised on outriggers or parked over an
inspection
pit.
–
The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
s
W
M 1
Designation Quantity GROVE part no.
Gasket 30 x 36 Cu DIN 7603 1 00117151
