Maintenance work on the carrier
7.11 Vehicle brake
7 - 76 3 302 364 en Maintenance manual
GMK 4100L-1
25.11.2016
If the symbol (1) is displayed on the on-board computer, one of the disc
brakes has exceeded the brake pad wear limit.
• Check all disc brakes on all axle lines; à Checking disc brakes, p. 7 - 76.
• Have the disc brakes repaired immediately; à Having the brakes repaired,
p. 7 - 81.
7.11.2 Checking disc brakes
Spare parts
and tools
– Measuring tools for brake pad and brake disc thicknesses.
– Dial gauge for the brake disc runout.
– Ring spanner for adjustment.
Prerequisites – The truck crane must be parked over an inspection pit.
– The truck crane must be raised on outriggers.
– The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
– The wheels must be removed from all the axle lines.
– The parking brake must be released.
M 3
Designation Quantity GROVE part no.
Wear contact set 12 03142924
Set of brake pads with a wear
contact set
12 03142923
Guide set and packing set 24 03142922
Packing set 24 03142925
Brake disc 8 03142916
