Maintenance overview
5.2 Maintenance plans
5 - 14 3 302 364 en Maintenance manual
GMK 4100L-1
25.11.2016
5.2.6 Maintenance plan M 12
M 12
Maintenance work on the CARRIER:
every 12 months/after 20,000 – 25,000 km ( 12,430 – 15,530 mi)
Engine
–Notes;
à Engine manufacturer’s documentation à p. 7 - 13
– Have the radiator checked/cleaned
à p. 7 - 18
– Checking the V-belt tension
à p. 7 - 23
Fuel system
– Replacing fuel filter 2
à p. 7 - 31
Exhaust system with exhaust emission control
– Having the AdBlue system checked
à p. 7 - 37
Transmission
– Checking the oil level
à p. 7 - 41
Axle lines
– Axle centre drives – changing the oil
à p. 7 - 57
– Final drives – Changing the oil
à p. 7 - 62
Suspension
– Pressure accumulator – checking the gas pressure
à p. 7 - 87
Compressed air system
– Replacing the filter cartridge of the compressed air drier
à p. 7 - 95
Hydraulic system
– Changing the ventilation filter
à p. 7 - 101
– Taking oil samples:
depending on the
oil sample test results:
– Changing the hydraulic oil
à p. 7 - 102
à p. 7 - 107
– Changing the hydraulic oil filter
à p. 7 - 111
Air-conditioning system
– Cleaning the condenser fins
à p. 7 - 128
– Checking the entire air-conditioning system
à p. 7 - 128
– Changing the pollen filter
à p. 7 - 130
Other maintenance work
– Lubricating the cab door
à p. 7 - 141
– Lubricating the connecting and socket pins
à p. 7 - 142
– Renewing the corrosion protection
à p. 7 - 143
