Maintenance work on the carrier
7.4 Fuel system
7 - 28 3 302 719 en Maintenance manual
GMK6300L-1
13.02.2018
• Remove the cover (1).
• Remove the old filter (3) from the casing.
• Place the old filter (3) in the receptacle.
• Insert a new filter (3) and a new gasket (2)
into the housing.
• Attach the cover (1) – torque 55 Nm
(40.5 lbf ft);
à Engine manufacturer’s
documentation
.
• Remove the receptacle.
• Open the valve (2) – lever parallel to the line.
• Open the tank cover on the fuel tank;
à p. 7 - 25.
• Operate the hand pump (1) until you sense
definite resistance.
• Close the tank cover on the fuel tank.
• Start the engine and check for leaks.
H
If you have used a clean receptacle, you can refill the fuel tank with the
consumable using a filter.
Otherwise dispose of the consumable properly.
