Manitowoc Grove GMK6300L-1

Maintenance work on the carrier
7.9 Wheels
7 - 62 3 302 719 en Maintenance manual
GMK6300L-1
13.02.2018
7.9.2 Checking the tyre pressure
•
Check the tyre pressure using the following table.
W
S
Risk of damage to the tyres.
The tyre pressure increases during operation. Never release the increased
air pressure of tyres at opera
ting temperature.
Always check the tyre pressure in on-road driving mode with cold tyres.
Tyres Air pressure of cold tyres in bar
(psi)
14.00 R 25 10.0 (145)
14.00 R 25 X Crane 9.0 (131)
16.00 R 25 9.0 (131)
17.50 R 25 7.0 (102)
20.50 R 25 7.0 (102)
385/95 R25 10.0 (145)
445/80 R25 7.0 (102)
445/95 R25 9.0 (131)
525/80 R 25
7.0 (102)
