Manitowoc Grove GMK6300L-1 Maintenance Manual

Maintenance work on the carrier
7.10 Vehicle brake
13.02.2018
Maintenance manual 3 302 719 en 7 - 69
GMK6300L-1
7.10 Vehicle brake
7.10.1 Checking brake lining thickness
Spare parts and
tools
– Measuring tool for brake linings.
Prerequisites – The truck crane must be parked over an inspection pit.
– The truck crane must be raised on outriggers.
– The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
– The parking brake must be released.
Safety
instructions
• Do not perform repair work on the vehicle brakes; à Maintenance
instructions
, p. 1 - 2.
• Perform only maintenance work; à Checking, p. 7 - 70.
s
M 3
Designation Quantity
per axle
line
GROVE part no.
1. and 2nd axle line (duplex brake)
Brake shoe with brake lining 4 03322112
Spring 4 03322110
Brake drum 2 01925703
3. to 6th axle line (simplex brake)
Brake shoe with brake lining 4 03322121
Spring 4 02315393
Brake drum 2 01925703
G
Risk of accidents due to incorrect work on the vehicle brakes.
Incorrect work on the vehicle brakes can lead to failure of the brakes
causing severe accidents.
Incorrect
work invalidates the operating licence of the truck crane and
no cla
ims of liability for damage can then be accepted.
All repair work on the vehicle brakes may only be performed by
Manitowoc Crane Care or an authorised GROVE dealer or an authorised
specialist workshop with specially trained repair crew.
