Manitowoc Grove GMK6300L-1 Maintenance Manual

Maintenance work on the superstructure
8.13 Central lubrication system
13.02.2018
Maintenance manual 3 302 719 en 8 - 107
GMK6300L-1
8.13 Central lubrication system
8.13.1 Checking the level
The maintenance of the pump (1) is the same
as the maintenance on the carrier;
à Central
lubrication system
, p. 7 - 99.
Connected lubricating points
– Main hoist drum,
– Slewing bearing,
– Telescopic unit – pivot pins,
– Derricking cylinder – pivot pins
Lubricating points not connected
– Auxiliary hoist drum;
à p. 8 - 43.
