Manitowoc Grove GMK6300L-1 Maintenance Manual

Maintenance work on the carrier
7.16 Electrical system
13.02.2018
Maintenance manual 3 302 719 en 7 - 109
GMK6300L-1
7.16.5 Check the external starting socket
The battery box can be equipped with an external starting socket (1)
as additional equipment.
Accessories
A connection cable (1) for the e
x
ternal starting socket is supplied with
the truck crane (tool set).
The battery box can also be equipped with a battery charger as additional
equipment.
• Consult the operating instructions supplied with the battery charger and
regularly check that all components are functioning correctly to ensure
that the external starting socket, connecting cable and battery charger
are ready for operation if needed;
à Manual de instrucciones.
Checking
• Remove the cap (4) from the socket (1).
• Check that the cap is not damaged and
is secured with the chain (3).
• If necessary, clean the poles (2).
• Attach the cap – the cap must be fitted
tightly and compactly on the socket.
M 3
Designation GROVE part no.
Connecting cable with two plugs;
Length 12 m
03143281
