Manitowoc Grove GMK6300L-1 Maintenance Manual

Maintenance work on the carrier
7.14 Hydraulic system
7 - 86 3 302 719 en Maintenance manual
GMK6300L-1
13.02.2018
7.14.6 Taking oil samples
Reducing the
interval
• Under difficult operating conditions – at tropical or very hot locations –
you must halve the oil change interval.
Spare parts and
tools
– A hose with a connecting piece for a gauge port.
– A sample container 0.3 litres (0.08 gal)).
– Receptacle, approx. 5 litres (1.5 gal);
à p. 2 - 4.
Prerequisites – The engine must have run for an adequate time beforehand, in order to fill
the pressure accumulator for the steering;
à p. 7 - 76.
– During the oil test the engine must be switched off and be secured against
unauthorised use
;
à p. 2 - 3.
Select the
sampling location
To determine the usab
ility of the oil, you must take a sample from the
hydraulic system. To do that you must connect the hose with the
connecting piece to a gauge port.
The gauge port (1) is located on the control
block (2) for the steering.
• Clean the gauge port before connecting
the hose.
M 12
Hose lengths GROVE part no.
1 m (3.3 ft) 01923003
2 m (6.6 ft) 00551941
4 m (13.2 ft) 01923139
GROVE part no.
A set of sample containers with protective mailing bag
and delivery note to the contracted laboratory
03141012
