Maintenance work on the superstructure
8.4 Fuel system
8 - 28 3 302 719 en Maintenance manual
GMK6300L-1
13.02.2018
8.4.1 Draining off water from fuel filter 1
Optional As an option, the truck crane GMK6300L-1 can be fitted with the fuel filter 1.
This allows water to be removed from the fuel more easily.
Spare parts and
tools
– Receptacle, approx. 5 ltr (1.5 gal);
à p. 2 - 4.
Prerequisites – The truck crane must be level.
– The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
Draining off water
• Place a receptacle underneath the filter.
• Open the valve (1).
• If the consumable that emerges is clean,
close the valve by hand.
• Remove the receptacle and properly
dispose of the drained consumable.
O
Risk of environmental damage due to leaking consumables.
Always let consumables drain into suitable receptacles. Wipe up any
consumables tha
t escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
