Maintenance work on the carrier
7.3 Engine
13.02.2018
Maintenance manual 3 302 719 en 7 - 17
GMK6300L-1
7.3.6 Have the radiator checked/cleaned
Reducing the
interval
• Under difficult operating conditions – at extremely sandy or dusty
locations or if there is a heavy density of fallen leaves – you must
have the radiator fins cleaned earlier than this.
Prerequisites – The truck crane must be supported on outriggers and must be level;
à Manual de instrucciones.
– The main boom must be fully retracted and raised to 75°;
à Manual de
instrucciones
.
– The engine must be switched off and secured against unauthorised
use;
à p. 2 - 3.
– The working area on the carrier above the engine covers and between
the r
adiator units must be freely accessible.
– Trained repair crew and repair tools must be available.
Check the level
of
dirt
s
s
