Maintenance work on the carrier
7.6 Transmission
13.02.2018
Maintenance manual 3 302 719 en 7 - 37
GMK6300L-1
7.6 Transmission
7.6.1 Checking the oil level
Prerequisites – The truck crane must be level.
– The parking brake must be applied.
– The transmission must be in neutral position N.
Sequence of
checks
• Check the oil level in the transmission daily in this sequence:
– prior to starting the engine;
à p. 7 - 38.
– when the gear oil is cold;
à p. 7 - 38.
– when the gear oil is warm;
à p. 7 - 39.
H
To prevent damage to the transmission, the oil level check is always most
accurate when the gear oil is warm.
H
When the engine is running, the gear oil level will continue to be monitored
by the oil level sensor;
à Manual de instrucciones.
s
S
Risk of damage to the transmission.
If the oil level is too low or too high, this can lead to malfunctions
and dama
ge to the transmission.
Carry out the oil level checks in the sequence specified.
