Manitowoc Grove GMK6300L-1 Maintenance Manual

Maintenance work on the carrier
7.14 Hydraulic system
7 - 84 3 302 719 en Maintenance manual
GMK6300L-1
13.02.2018
Cleaning the
magnetic rods
• Release the cap (1) and pull out the filters.
• Place the filters in a receptacle.
• Remove the spring (2).
• Undo the nut (5).
• Take the magnetic rod (3) out of the
filter cage (4) and clean it.
• Replace any damaged parts,
where necessary.
• Assemble the filters and install them.
• Replace the gaskets if necessary and
fasten the cap (1).
• Start the engine and check for leaks.
S
Risk of damage to the hydraulic system
Large amounts of metal particles are a sign of damage in the hydraulic
system. Have the hydraulic system checked by
Manitowoc Crane Care or
an authorised GROVE dealer or your repair crew.
