Maintenance work on the carrier
7.18 Towbar coupling
7 - 116 3 302 719 en Maintenance manual
GMK6300L-1
13.02.2018
Closing the
towbar coupling
After lubrication you must close the
towbar coupl
ing.
• Move the lever (1) briefly in the direction
of the coupling jaw (observe the arrow).
• Remove any grease that emerges.
G
Risk of injury when manually closing the towbar coupling
When closing, the lever moves down with great force in the direction of the
coupling jaw. Start the closi
ng process only by moving the lever briefly in
the direction of the coupling jaw with the ball of your hand.
If you hold the lever and move it down, it may carry your hand with it
and crush it.
