Maintenance work on the superstructure
8.4 Fuel system
8 - 30 3 302 719 en Maintenance manual
GMK6300L-1
13.02.2018
• (A) – Remove the filter element (2) and the
filter (1).
If necessary, replace any damaged parts.
• (B) – Screw on a new filter (1) and the filter
element (2).
• Close the valve (3) manually.
• Open the valve – lever (3) parallel to the line.
• Actuate the pump (2) until the fluid flowing
out of the screw plug (1) no longer contains
any bubbles.
• Tighten the screw.
• Start the engine and check for leaks.
• Remove the receptacle.
H
If you have used a clean receptacle, you can refill the fuel tank with the
consumable using a filter.
Otherwise dispose of the consumable properly.
