Torques
10.2 Special torques
10 - 2 3 302 719 en Maintenance manual
GMK6300L-1
13.02.2018
10.2 Special torques
Name
Thread size
(mm)
Size across flats
(mm)
Torque (Nm)
Hexagon-
head bolt
Socket
screw
Suspension strut:
Bracket for the vehicle chassis, top M 16 14 265
Bracket for the vehicle chassis,
bottom
M 24 19 900
Suspension strut flange, bottom M 20 17 520
Half shell steering lever M 16 14 265
Steering linkage:
Ball-and-socket joints and
steering track rods
M 10 x 1
M 12 x 1.5
M 14 x 1.5
M 24 x 1.5
M 30 x 1.5
45 - 55
70 - 85
140 - 160
250 - 280
450 - 500
Others:
Coolant hose clamps 4
Wheel nuts M 22 x 1.5 32 650
Rim connection bolts
(on
ly for alumi
nium rims)
Aluminium rims with 20 nuts 550
Aluminium rims with 22 nuts 385
Retaining bolts for the
Slewing be
aring
M 27 1150
Hoist drum rope clamp M 14 2 nuts
78
