FlyMarker

mini 85/45 plus and 120/45 plus

Operating Manual

The second level of the Files window appears.

Level 2

3. Press F8.

Depending on the mode selected

either:

Only marking files are shown.

or:

Only logos, fonts and CSV files are shown.
