FlyMarker

mini 85/45 plus and 120/45 plus

Operating Manual

3.5.6 Description of function keys

F1 = Shift key (standard characters ↔ special characters)

F2 = File manager

F3 = Parameter menu

F4 = Insert substitute

F5 = Preview

F7 = Settings

F8 = Information

F9 = Language

F10 = Teach-in

All described function keys (F1 - F10) in this operating manual refer to the following buttons:
