5.2.2.4 Text-circle
Text and variables are marked in a circle.
Mode
Text circle
X center
Indicates the X coordinates of the center of the circle, around whose radius the text is to be
marked. See image above.
Y center
Indicates the Y coordinates of the center of the circle, around whose radius the text is to be
marked. See image above.
Radius
Indicates the radius of the circle on whose arc the text is to be marked. See image above.
Center of circle
X coordinates of the circle’s center
Y coordinates of the circle’s center
Radius
