Mash Seventy - Page 51

Chapter 3 Engine Section 3 Engine dissassembly
3—13
Remove the washer ③, bearing , push rod and ④ ②
push rod .⑤
As in Fig.3.3.21
Leveling clutch spline sleeve safety washer.
As in Fig.3.3.22
Use a special tool to remove the clutch spline sleeve
nut.①
Tools: clutch sleeve clamp ②
Remove the clutch spline sleeve .③
As in Fig.3.3.23
Remove the thrust washer and clut④ ch hub
assembly .⑤
As in Fig.3.3.24
Remove the bushing and thrust washer .⑦ ⑥
As in Fig.3.3.25
Fig.3.3.21
5
2
3
4
Fig.3.3.22
1
Fig.3.3.23
2
3
Fig.3.3.24
5
4
Fig.3.3.25
6
7
