Maxcess FIFE DP-20 PLUS User Manual

DP-20 PLUS Web Guide Controller 4-3
4th Quarter 2021 © 2021 Maxcess International. All rights reserved. Figure Sheet 2-320 A
5. Use the ARROW keys to scroll to the desired
Measurement menu. Next in the list is the Servo-
Center Sensor. The sensor signal is displayed
on Line 4.
6. Use the ARROW keys to scroll to the desired
Measurement menu. Next in the list is the
MOTOR TYPE. The motor type is displayed on
Line 4.
7. Use the ARROW keys to scroll to the desired
Measurement menu. Next in the list is the
TACHOMETER. The motor tachometer signal is
displayed on Line 4. Press the ENTER key to
switch between percentage and RPM display
modes. The percentage value shown is relative
to the maximum speed of the attached motor.
8. Use the ARROW keys to scroll to the desired
Measurement menu. Next in the list is the
MOTOR CURRENT. The motor current value is
displayed on Line 4. Press the ENTER key to
switch between percentage and ampere display
modes. The percentage value shown is relative
to the maximum current of the attached motor.
9. Use the ARROW keys to scroll to the desired
Measurement menu. Next in the list is the
DIGITAL I/O. The state of the digital outputs and
inputs are displayed on Line 4. The order in
which the inputs are displayed is shown in the
following table.
OUT
IN
A
B
5
4
3
2
1
0
10. If desired, use the ARROW keys to scroll until
EXIT MENUS is displayed on line 3. Pressing
the ENTER key while this screen is displayed will
exit the Measurement Menus and return to the
Operator Level.
11. Otherwise, press the MANUAL key to exit the
Measurement Menus and return to the Operator
Level.
1C
AUTOMATIC
×Ø -ãããããÜÜÜÜÜ+
×Ø 1C.3.3
MEASUREMENT
~ƒ SENSOR (X2)
-ããããÜÜÜÜ+ 50%
×Ø 1C.3.4
MEASUREMENT
MOTOR TYPE
0.6A MOTOR 8.66K
×Ø 1C.3.5
MEASUREMENT
TACHOMETER
-ãããããããá+ +89%
×Ø 1C.3.7
MEASUREMENT
DIGITAL I/O (X3)
10000000
×Ø 1C.3.8
MEASUREMENT
EXIT MENUS
×Ø 1C.3.6
MEASUREMENT
MOTOR CURRENT
-ãããÜÜÜ+ +50%
×Ø 1C.3.5
MEASUREMENT
TACHOMETER
-ãããããããá+ 1190R
×Ø 1C.3.6
MEASUREMENT
MOTOR CURRENT
-ãããÜÜÜ+ +0.15A
