Maxcess FIFE DP-20 PLUS User Manual

DP-20 PLUS Web Guide Controller 1-1
4th Quarter 2021 © 2021 Maxcess International. All rights reserved. Figure Sheet 2-320 A
1 INTRODUCTION
DP-20 PLUS General Information
The DP-20 PLUS Web Guide Controller is another Maxcess International advancement in
technology that provides superior guiding performance.
This controller is able to operate in a variety of sensor modes, such as Fixed-Sensor Center Guide
or Edge Guiding from either edge. Edge of Line or Center of Line Guiding is also supported.
The DP-20 PLUS can be either wall-mounted or panel-mounted with included bezel.
The DP-20 PLUS Web Guide Controller is designed to control one motor, up to and including a
3.5 Amp motor, provided by Maxcess International.

Maxcess FIFE DP-20 PLUS Specifications

General

Brand	Maxcess
Model	FIFE DP-20 PLUS
Category	Controller
Language	English
