3 SETUP MENU STRUCTURE
Setup Menu Notes
1. The SETUP key is used to enter the Setup Menus.
2. The ENTER key is used to store changes in the Setup Menus.
3. Pressing the MANUAL key in most Setup Menus will exit the Setup Menus and return to
the Operator Level. All changes that were not previously stored will be discarded.
4. In the Setup Menu Structure, at the end of each string of menu selections is an EXIT
MENUS screen. Pressing the ENTER key while this screen is displayed will exit the Setup
Menus and return to the Operator Level. No values or settings are stored.
5. While in most of the Setup Menus, if no key is pressed within 3 minutes, the system will
automatically exit the Setup Menus and return to the Operator Level. While in Automatic
Mode or Servo-Center Mode, the Gain and Guide Point changes are stored. While in
Manual Mode, all changes that were not previously stored are discarded.
6. While in the Setup Menus, if “FAILED“ is displayed, the MANUAL key must be pressed to
exit the Setup Menus and return to the Operator Level.
7. If a menu is password protected, the letter “X“ will be indicated to the left of the menu
number.
8. The Menu Number, located at the right end of line 1 of the LCD Panel, will contain 2 or
more digits with the second and subsequent digits separated by dots. The Menu Number
is defined as follows;
1A.2.3.4.5
MENU NUMBER
1
OPERATION MODE *
_A
SENSOR MODE/INPUT **
__.2
MENU LEVEL
__._.3
MENU ITEM
__._._.4.5
MENU ITEM SETTINGS
* 1 = Automatic, 2 = Servo-Center, 3 = Manual
** A = Edge Left, B = Edge Right, C = Center (both edges)
D = Line Center, E = Line Edge, F = Servo-Center.
