Maxcess FIFE DP-20 PLUS User Manual

DP-20 PLUS Web Guide Controller 2-2
4th Quarter 2021 © 2021 Maxcess International. All rights reserved. Figure Sheet 2-320 A
Features of the LCD Panel
LINE 1 This line contains the menu number. This number may contain
2 or more digits. The first digit indicates the current operation mode. The
second digit indicates the current sensor mode. The subsequent digits
indicate the current Setup Menu (when applicable).
LINE 1 When the letter “X“ precedes the menu number, this indicates
that the selected menu is password protected. When an attempt is made
to enter this menu, a password will be requested. T
LINE 1 While in Servo-Center mode, the symbol of the current sensor
selection is displayed in this line.
LINE 1 While in the setup menus, the symbol of the current sensor
selection is displayed in this line.
LINE 1 A command present on the Digital I/O is indicated by an asterisk
in this line.
LINE 1 An External Lock command present on the Digital I/O is indicated
by an asterisk surrounded by parentheses in this line.
LINE 1 An unrecognized command present on the parallel port is
indicated by a question mark in this line.
LINE 1 While in any of the setup menus, a flashing dot (see arrow) in
this line indicates that a timer is running. The DP-20 PLUS is waiting for
a response from the operator. If no response is detected in 3 minutes,
the unit will return to the Operator Level. If this dot is not flashing, no
timer is active.
LINE 2 While at the Operator Level, this line contains the name of the
currently selected Operation mode.
LINE 2 While in the setup menus, this line indicates that a Setup Menu
has been selected and indicates the current Operation Mode.
× 3A.2.3.1
SETUP (MAN)
GUIDE POLARITY
+
× 2A
SERVO CENTER
~ƒ -ãããããÜÜÜÜÜ+
×Ø 2C.1.1
SETUP (SC)
~ƒ GAIN
ãÜÜÜÜÜÜÜÜÜ 5.0%
1A
AUTOMATIC
× -ãããããÜÜÜÜÜ+
× 3A.2.2
SETUP (MAN)
GUIDE POINT
-ÜÜÜÜåÜÜ+ +20.0%
* 1A
AUTOMATIC
× -ãããããÜÜÜÜÜ+
× X3A.2.3.1
SETUP (MAN)
GUIDE POLARITY
+
? 1A
AUTOMATIC
× -ãããããÜÜÜÜÜ+
(*) 1A
AUTOMATIC
× -ãããããÜÜÜÜÜ+
×Ø 2C.1.1
SETUP (SC)
~ƒ GAIN
ãÜÜÜÜÜÜÜÜÜ 5.0%
