DP-20 PLUS Web Guide Controller 10 1
4th Quarter 2021 © 2021 Maxcess International. All rights reserved. Figure Sheet 2-320 A
1 SPECIFICATIONS
General
Universal Input Line
Voltage Range - 90 VAC To 250 VAC
Input Line Frequency - 50 To 60 Hz
Power consumption - 180 VA
Operating Ambient - 0° to 50°C (32° to 122°F)
Temperature
Dimensions - Height 144 mm (5.67”)
Width 144 mm (5.67”)
Depth 103 mm (4.06”) (without cables attached)
Approximate - 1.6 Kg (3.5 lbs)
Weight
Inputs and Outputs
Electromechanical Actuator - 3.5 A, 46 V maximum
Hydraulic Servo Valve - ±50 mA
With or without Lockout Valve (Max 39 W at 24 V or 48 V)
MPA (with MPA Lockout Signal) - ±10 mA
Servo Center - Analog Inductive type
Sensor Input (2) Individually - Max Input ±20 mA
Programmable 0 to 10 mA (Preferred)
Parallel port - Six Digital Inputs
Low Level: 0 – 0.9 V
High level: 4.6 – 24 V, max 6 mA
Two open collector outputs connected to ground, max 30 V
(NPN open collector) 55 mA at 1.6 V
Switchable Logic Polarity
+12V / +15V available to port for input reference
Supply to Sensors +12V or +15V ±5%, 600 mA (+15V for legacy FNA sensors)
Supply to Accessories + 12V ±5% 100 mA
