414
Practical hints
Flat tire
Lifting the vehicle
1 Wheel chock
왘 Prevent the vehicle from rolling away
by blocking wheels with wheel
chock 1 and another sizable suitable
objects.
When changing wheel on a level sur-
face:
왘 Place wheel chock 1 in front of
and another sizeable suitable ob-
ject behind the wheel that is diag-
onally opposite to the wheel
being changed.
Always try lifting the vehicle using
the jack on a level surface. However,
should circumstances require you to
do so on a hill, place the wheel chock
and the other sizeable, heavy object
as follows:
왘 Place wheel chock 1 and another
sizeable suitable object on the
downhill side blocking both
wheels of the axle not being
worked on.
2 Two-piece wheel wrench
왘 Take the two-piece wheel wrench 2
out of the vehicle tool kit tray. As-
semble wheel wrench.
왘 On wheel to be changed, loosen but
do not yet remove the wheel bolts
(approximately one full turn with
wrench).
The tube openings are located directly
behind the front wheel housings and in
front of the rear wheel housings.
Warning! G
The jack is designed exclusively for jacking
up the vehicle at the jack support tube
hole built into the vehicle. To help avoid
personal injury, use the jack only to lift the
vehicle during a wheel change. Never get
beneath the vehicle while it is supported
by the jack. Keep hands and feet away
from the area under the lifted vehicle. Al-
ways firmly set parking brake and block
wheels before raising vehicle with jack.
Do not disengage parking brake while the
vehicle is raised. Be certain that the jack is
always vertical (plumb line) when in use,
especially on hills. Always try to use the
jack on level surface. Make sure the jack
arm is fully seated in the jack support tube
hole. Always lower the vehicle onto suffi-
cient capacity jackstands before working
under the vehicle.
