12.7.1.2 Network (MDH 860, 861, 862, 863)
Network
MDH 860, MDH 861, MDH 862, MDH 863
Enter a free LAN IP address and the subnet mask from
your system or machine network here.
Activate the "1:1NAT Network" when both tunnel end
points have the same network address to enable communi-
cation through both networks.
NOTICE
Make sure that the LAN IP and WAN IP are in different address ranges.
Wi-Fi Settings (MDH 863)
SSID Enter the name of the wireless net-
work to which the device should con-
nected.
Authentication Mode Select the authentication method from
the selection list.
Encryption Mode Select the encryption method.
Encryption Key Enter the Encryption Key.
Encryption Key confir-
mation
Repeat the entered Encryption Key.
Kanal Chose a Wi-Fi channel from the se-
lection list.
Then go to the "Internet" tab.
Page 60 von 131 | Version: 2.2.1 - EN | Mar 28
th
, 2022 |
